Assembly
record.
WM—01 / A–D
Read the parts as a system.
From separated elements to a complete object.
Fit & relationship
This concept record explains the intended relationships. It is not an instruction to manufacture or assemble an electrical product.
PARTROLE / CONNECTION
A / Light headOptical element + connector
The shallow circular head carries the diffuser. A visible connector joins the head to the arm so that the lighting element remains readable as a separate component.
B / Pivot armReach + adjustment
The short horizontal arm offsets the light from the mast. A contrasting circular knob marks the intended adjustment point; its final travel and locking mechanism require engineering.
C / MastHeight + threaded fit
A cylindrical mast establishes the working height. Threaded ends express how the base and upper arm connect. Thread size, tolerances and cable routing are unresolved concept details.
D / BaseSupport + stability
The shallow circular base provides a visual counterweight to the head. Material weight, stability testing and surface protection would be specified in development.
